What is the recommended way to load vocabulary into Postgres?

Vocabulary Users
#1

Hi folks,

This may be very basic question but what is the recommended way to load vocabulary data from the csv files downloaded from athena.ohdsi.org into a postgres database?

I know there was a sql script created by Lee Evans using ‘copy from’ in 2014. Is there any other/better /recommended way to do it?

Thanks,
Ray Zohdsi

#2

You can use the Data Description Language (DDL) scrips to create the tables correctly (https://github.com/OHDSI/CommonDataModel/tree/main#readme). From there, loading the vocabularies from Athena should be a mere matter of inserting rows on the tables… although the CSV files can be big.

The ETL-Synthea repo (https://github.com/OHDSI/ETL-Synthea) has a function to load those CSV files (LoadVocabFromCsv()), but I wonder if the same could be accomplished with import features from general-purpose SQL clients, e.g. Import/Export Data Dialog — pgAdmin 4 6.7 documentation.

Kind regards.

#3

Thank you so much, Fabrício! This is what I have been looking for.

Ray

#4

I use ETL-Synthea to import and got the warning message:

Warning messages:
1: In data.table::fread(file = paste0(vocabFileLoc, "/", csv), stringsAsFactors = FALSE,  :
  Found and resolved improper quoting out-of-sample. First healed line 853636: <<2614984        "y set" tubing for peritoneal dialysis  Device  HCPCS   HCPCS   S       A4719   20020101        20991231        >>. If the fields are not quoted (e.g. field separator does not appear within any field), try quote="" to avoid this warning.
2: In data.table::fread(file = paste0(vocabFileLoc, "/", csv), stringsAsFactors = FALSE,  :
  Found and resolved improper quoting out-of-sample. First healed line 115727: <<44833612       "ventilation" pneumonit 4180186>>. If the fields are not quoted (e.g. field separator does not appear within any field), try quote="" to avoid this warning.
>
#5

The function data.table::fread() is having trouble with quotes. Disabling them (quote = “”) should fix. The vocabulary files do not use quoting.

#7

Sorry Fabricio,
I thought I knew how to use it but I don’t. How to pass the quote="" to disable them?

Thanks,
Ray Z.

#8

Zohdsi,

Truth is, I confused myself in the answer too, sorry. I was talking about fread() instead of LoadVocabFromCsv().

What worked for me was to copy the code from LoadVocabFromCsv(). If you just enter this in the R console:

> ETLSyntheaBuilder::LoadVocabFromCsv

You get the code of the function:

function (connectionDetails, cdmSchema, vocabFileLoc, bulkLoad = FALSE)
{
csvList ← c(“concept.csv”, “vocabulary.csv”,
“concept_ancestor.csv”, “concept_relationship.csv”,
“relationship.csv”, “concept_synonym.csv”,
“domain.csv”, “concept_class.csv”, “drug_strength.csv”)
fileList ← list.files(vocabFileLoc)
fileList ← fileList[which(tolower(fileList) %in% csvList)]
conn ← DatabaseConnector::connect(connectionDetails)
for (csv in fileList) {
vocabTable ← data.table::fread(file = paste0(vocabFileLoc,
“/”, csv), stringsAsFactors = FALSE, header = TRUE,
sep = “\t”, na.strings = “”)
vocabTable ← as.data.frame(vocabTable)
if (tolower(csv) == “concept.csv” || tolower(csv) ==
“concept_relationship.csv” || tolower(csv) ==
“drug_strength.csv”) {
vocabTable$valid_start_date ← as.Date(as.character(vocabTable$valid_start_date),
“%Y%m%d”)
vocabTable$valid_end_date ← as.Date(as.character(vocabTable$valid_end_date),
“%Y%m%d”)
}
writeLines(paste0("Loading: ", csv))
suppressWarnings({
DatabaseConnector::insertTable(conn, tableName = paste0(cdmSchema,
“.”, strsplit(csv, “[.]”)[[1]][1]),
data = as.data.frame(vocabTable), dropTableIfExists = FALSE,
createTable = FALSE, useMppBulkLoad = bulkLoad,
progressBar = TRUE)
})
}
on.exit(DatabaseConnector::disconnect(conn))
}
<bytecode: 0x000001eacefcb118>
<environment: namespace:ETLSyntheaBuilder>

So you can copy the code to create your own function equal to LoadVocabFromCsv(), but with quote = "" in the call to data.table::fread().

Hope that works for you.

Kind regards.

#9

This works too:

t
